D-Link DCS-8302LH Full HD Weather-Resistant Pro Wi-Fi Camera
The D-Link DCS-8302LH is a fixed-view Full HD camera with both Wi-Fi and Ethernet networking. It captures 1080p video at 30 frames per second across a 135-degree view, with infrared night vision specified up to five metres.
Useful features
At a glance1080p at 30 fps
1080p at 30 fps: defines the video capture rate.
135-degree fixed view
135-degree fixed view: covers the angle without motorised pan and tilt.
Infrared up to five metres
Infrared up to five metres: supplies the conditional night-vision capability.
Person detection
Person detection: provides the manufacturer's event classification.
Two-way audio and siren
Two-way audio and siren: uses the built-in microphone and speaker functions.
Wi-Fi or Ethernet
Wi-Fi or Ethernet: offers 2.4 GHz wireless or 10/100 wired networking.
microSD up to 256 GB
microSD up to 256 GB: supports a separate compatible local-storage card.
ONVIF Profile S
ONVIF Profile S: allows compatible recording-system integration.
Sheltered outdoor installation
Sheltered outdoor installation: requires the cover, downward plug and exposure limits.
Mounting accessories included
Mounting accessories included: lists screws, cable ties and an Ethernet seal in the pack.
The useful features
- 1080p at 30 fps: defines the video capture rate.
- 135-degree fixed view: covers the angle without motorised pan and tilt.
- Infrared up to five metres: supplies the conditional night-vision capability.
- Person detection: provides the manufacturer's event classification.
- Two-way audio and siren: uses the built-in microphone and speaker functions.
- Wi-Fi or Ethernet: offers 2.4 GHz wireless or 10/100 wired networking.
- microSD up to 256 GB: supports a separate compatible local-storage card.
- ONVIF Profile S: allows compatible recording-system integration.
- Sheltered outdoor installation: requires the cover, downward plug and exposure limits.
- Mounting accessories included: lists screws, cable ties and an Ethernet seal in the pack.
The useful details
Know what
you’re getting.
The D-Link DCS-8302LH is a fixed-view Full HD camera with both Wi-Fi and Ethernet networking. It captures 1080p video at 30 frames per second across a 135-degree view, with infrared night vision specified up to five metres.
Networking can use 2.4 GHz Wi-Fi or 10/100 Ethernet. The mydlink setup requires a compatible app, account, router and internet connection. Recording options include a separate microSD card up to 256 GB, an eligible mydlink cloud plan or a compatible ONVIF Profile S recorder. Each option has its own storage, service and configuration requirements; cloud access is not a promise of unrestricted free recording.
For outdoor use, D-Link directs installation under eaves or similar shelter, with the rubber plug facing down and no continuous water exposure. The supplied power adapter also needs the protection required by the instructions. The camera has no motorised pan-and-tilt mechanism, so positioning establishes the view.
Mount securely in a sheltered location. For outdoor use, D-Link directs installation under eaves or similar cover, with the rubber plug facing down and no continuous water exposure. Use the included 12 V/1 A adapter, an Internet connection, a router, and the mydlink app on a compatible iOS or Android device; app registration requires an email account.
A fixed-view Full HD camera with Wi-Fi and Ethernet.
Monitors an indoor or supported sheltered outdoor area and provides two-way audio.
Monitors an indoor or supported sheltered outdoor area and provides two-way audio.
Useful for people who need this function: Monitors an indoor or supported sheltered outdoor area and provides two-way audio.
Monitors an indoor or supported sheltered outdoor area and provides two-way audio.
A closer look
Specifications.
The details that matter.
Specifications
What’s in the box
1 camera DCS-8302LH Full HD Wi-Fi camera
Rubber seal for Ethernet connection
Quick Installation Guide
Mounting screws and cable ties
Power adapter
Compatibility
2.4 GHz 802.11n/g Wi-Fi or 10/100 Ethernet for networking. The A1 manual requires a router and Internet connection for mydlink setup. Optional microSD recording supports cards up to 256 GB; the card is separate. ONVIF Profile S supports compatible recorder software/equipment.
App and setup
Mount securely in a sheltered location. For outdoor use, D-Link directs installation under eaves or similar cover, with the rubber plug facing down and no continuous water exposure. Use the included 12 V/1 A adapter, an Internet connection, a router, and the mydlink app on a compatible iOS or Android device; app registration requires an email account.
Weather resistance is not an immersion rating. Installation location, power-adapter protection and cloud service conditions require the manual.
A network, Internet connection, suitable mounting surface and power outlet are needed. A microSD card up to 256 GB is optional and not included; compatible ONVIF recorder or cloud service may be used for recording. The power adapter and mounting hardware in the package.
MicroSD card up to 256 GB for local recording
Compatible ONVIF recorder or optional mydlink cloud service
250 g camera body; D-Link AU product page states ±5%. This is not a shipping or packed mass.
138 × 88 × 62 mm camera dimensions. D-Link AU gives the three dimensions but does not label their axis order.
Included adapter: 100–240 V AC, 50/60 Hz input and 12 V DC 1 A output. Maximum camera consumption 7 W ±5%; cable length 3 m. 2.4 GHz 802.11n/g Wi-Fi, 10/100 Ethernet and RCM certification.
Care and safe use
The A1 manual limits outdoor placement to sheltered, covered locations with the rubber plug down; do not invert or expose continuously to water. Close the microSD cover before outdoor use. Disconnect power and wipe with a damp towel; do not submerge or clean with liquids or solvents. Technical-table operating range is -20 to 45 °C and up to 90% RH non-condensing.
