Eve · Wireless audio receivers
Eve Play AirPlay Audio Streaming Interface
Eve Play adds AirPlay reception to a suitable amplifier, receiver or active-speaker system. It lets a compatible Apple source send audio to equipment that already has an appropriate line-level or digital input, so an existing audio system can join the network-listening setup without replacing its speakers.
Useful features
At a glanceAirPlay reception
AirPlay reception: adds the supported network-audio input to suitable existing equipment.
Dual-band Wi-Fi
Dual-band Wi-Fi: supports the 2.4 and 5 GHz network connections.
Ethernet networking
Ethernet networking: provides a wired network option.
Stereo RCA output
Stereo RCA output: feeds a compatible line-level amplifier or active-speaker input.
Optical and coaxial outputs
Optical and coaxial outputs: provide digital connection alternatives.
TI PCM5122A converter
TI PCM5122A converter: identifies the analogue-output DAC.
Audio Sync adjustment
Audio Sync adjustment: offers automatic or manual delay control.
RCA cable and power supply included
RCA cable and power supply included: support the initial connection arrangement.
The useful features
- AirPlay reception: adds the supported network-audio input to suitable existing equipment.
- Dual-band Wi-Fi: supports the 2.4 and 5 GHz network connections.
- Ethernet networking: provides a wired network option.
- Stereo RCA output: feeds a compatible line-level amplifier or active-speaker input.
- Optical and coaxial outputs: provide digital connection alternatives.
- TI PCM5122A converter: identifies the analogue-output DAC.
- Audio Sync adjustment: offers automatic or manual delay control.
- RCA cable and power supply included: support the initial connection arrangement.
The useful details
Know what
you’re getting.
Eve Play adds AirPlay reception to a suitable amplifier, receiver or active-speaker system. It lets a compatible Apple source send audio to equipment that already has an appropriate line-level or digital input, so an existing audio system can join the network-listening setup without replacing its speakers. The unit is a receiver and interface, not a power amplifier.
Connect through stereo RCA analogue outputs using the supplied cable, or use the optical or coaxial digital output with a suitable separate lead. The analogue path uses a Texas Instruments PCM5122A digital-to-analogue converter. A local network connection can use 2.4 or 5 GHz Wi-Fi or Ethernet, and the supported Audio Sync function permits automatic or manual delay adjustment for the listening setup.
A current compatible iPhone or iPad is required for setup, together with the network and receiving audio equipment. Passive speakers cannot connect directly for amplified playback. Eve Play also does not send a record player or another external source out over AirPlay or Bluetooth; its role is receiving AirPlay audio. Playback resolution depends on the sending device and supported path. The package includes the interface, power supply, RCA cable and quick guide.
A mains-powered AirPlay audio receiver with analogue RCA and digital optical/coaxial outputs.
Adds AirPlay reception to a compatible amplifier, receiver or active-speaker system.
Streaming audio from a compatible Apple source into an existing amplifier, receiver or active-speaker system.
Households or small workplaces with the specifically required compatible ecosystem.
Connect Eve Play to an amplifier, receiver or powered speakers through a suitable line-level or digital input, join it to Wi-Fi or Ethernet, and send audio to it by AirPlay from a compatible Apple device.
A closer look
Specifications.
The details that matter.
Specifications
What’s in the box
Eve Play interface
Power supply
RCA audio cable
Quick Start Guide
Compatibility
A suitable amplifier, receiver or active-speaker system with RCA line-level or compatible optical/coaxial input, and an AirPlay source on the supported network.
Use and product notes
Connect the supplied RCA cable to a compatible line-level input, or use a suitable digital cable. Requires an amplifier, receiver or active speakers, a local Wi-Fi/Ethernet network and current iPhone/iPad for setup.
Keep the Audio Sync microphone unobstructed. Manufacturer instructs keeping the device on a private network, with no public internet port forwarding.
Receives AirPlay audio only. Playback resolution depends on the sending device.
Connect the supplied RCA cable to a compatible line-level input, or use a suitable digital cable. Requires an amplifier, receiver or active speakers, a local Wi-Fi/Ethernet network and current iPhone/iPad for setup.
131 × 126 × 26 mm
Power Input: 100 - 240 VAC / 50 Hz
