Lindy HDMI to VGA Converter
The Lindy 38291 converts an HDMI video output into analogue VGA for a compatible older monitor or projector. It provides a way to keep using a VGA display with an HDMI-equipped computer, for example as a presentation screen or a secondary workspace when the host supports that arrangement.
Useful features
At a glanceHDMI male to VGA female
HDMI male to VGA female: connects a digital HDMI source to a separate VGA display cable.
Legacy-display connection
Legacy-display connection: allows a compatible HDMI computer to feed a VGA monitor or projector in the direction.
Up to 1920 × 1200 at 60 Hz
Up to 1920 × 1200 at 60 Hz: provides the maximum video mode for a compatible display.
1080p support
1080p support: accommodates Full HD video where both the source setting and VGA display accept it.
Direct conversion without scaling
Direct conversion without scaling: requires the source resolution to match the receiving display's supported modes.
37 × 42 × 14.5 mm body
37 × 42 × 14.5 mm body: keeps the conversion electronics in the compact housing.
100 mm attached lead
100 mm attached lead: provides a short connection between the HDMI plug and converter body.
27 g net mass
27 g net mass: records the converter's product weight separately from its 37 g gross package weight.
The useful features
- HDMI male to VGA female: connects a digital HDMI source to a separate VGA display cable.
- Legacy-display connection: allows a compatible HDMI computer to feed a VGA monitor or projector in the direction.
- Up to 1920 × 1200 at 60 Hz: provides the maximum video mode for a compatible display.
- 1080p support: accommodates Full HD video where both the source setting and VGA display accept it.
- Direct conversion without scaling: requires the source resolution to match the receiving display's supported modes.
- 37 × 42 × 14.5 mm body: keeps the conversion electronics in the compact housing.
- 100 mm attached lead: provides a short connection between the HDMI plug and converter body.
- 27 g net mass: records the converter's product weight separately from its 37 g gross package weight.
The useful details
Know what
you’re getting.
The Lindy 38291 converts an HDMI video output into analogue VGA for a compatible older monitor or projector. It provides a way to keep using a VGA display with an HDMI-equipped computer, for example as a presentation screen or a secondary workspace when the host supports that arrangement.
The converter supports up to 1920 × 1200 at 60 Hz, including Full HD 1080p. It performs signal conversion without scaling, so the computer must be set to a resolution accepted by the receiving display. A display that cannot accept the selected mode will not gain that capability from the converter.
The attached 100 mm lead places the HDMI male plug near the compact 37 × 42 × 14.5 mm converter body. A separate VGA cable connects the female VGA output to the monitor. The 27 g product mass is the converter itself, rather than its packaged weight.
This is one-way HDMI-to-VGA conversion. VGA carries the picture and does not carry HDMI audio, so sound needs a separate suitable connection if required. The computer, VGA lead, monitor and any audio equipment are separate from the converter.
The Lindy 38291 allows an HDMI equipped computer to use a VGA monitor or projector.
The Lindy 38291 allows an HDMI equipped computer to use a VGA monitor or projector. It converts a digital HDMI video output into an analogue VGA signal, useful when a newer computer must connect to a legacy display.
The Lindy 38291 allows an HDMI equipped computer to use a VGA monitor or projector. It converts a digital HDMI video output into an analogue VGA signal, useful when a newer computer must connect to a legacy display.
The Lindy 38291 allows an HDMI equipped computer to use a VGA monitor or projector. It converts a digital HDMI video output into an analogue VGA signal, useful when a newer computer must connect to a legacy display.
Set the computer output to a resolution accepted by the VGA display.
A closer look
Specifications.
The details that matter.
Specifications
What’s in the box
1 unit HDMI to VGA converter
Compatibility
Connector A: HDMI Type A Male
Connector B: VGA Female
App and setup
Set the computer output to a resolution accepted by the VGA display.
Check port compatibility and route the lead or unit away from strain, moisture and heat.
An approximately 37 × 42 × 14.5 mm body and a 100 mm attached lead. The exact VGA display cable and any audio connection must be provided separately; VGA carries video rather than HDMI audio.
An approximately 37 × 42 × 14.5 mm body and a 100 mm attached lead. The exact VGA display cable and any audio connection must be provided separately; VGA carries video rather than HDMI audio.
27 g net
37 × 42 × 14.5 mm converter body; 100 mm attached lead
Housing Material: ABS
Connector Plating: Nickel
Pin Plating: Nickel
Colour: Black
Jacket Material: PVC
Conductor Material: Tinned Copper
